Today is Oct. 3rd 2024, and yesterday I was finally able to fire up the heat pump and get air-conditioning. And this morning get heating from the finally installed heat pump. A project I’ve been working on for months now. The heat pump had been installed less than a year when it failed in late May ’24.
If you remember last time I showed pictures of the shipping damaged heat pump delivered by FedEx. Than around 3 weeks after receiving that damaged one, AirXcel delivered another one, again by FedEx, but without shipping damage this time…except it was obvious that somewhere either the pallet was dropped, or a fork from a forklift caught a cross member on the pallet, or something heavy was placed on top, or the truck had hit a swale in the the road that caused a compression event. Which caused the heat pump to push down on the pallet, breaking a cross piece. So it was on a 10° tilt on the pallet when it arrived. Made the shipping guy stand there while I peeled back the wrapping and inspected. Eventually determined that it was likely just the compression event and there was zero damage to the heat pump as far as I could determine. So I signed.
Then it sat there on the pallet while I tried to arrange for muscle to move it. Two weeks passed and finally had a couple guys hired and they moved it to the platform next to the RV and it’s basement compartment. Opened the top, replaced the oil type pillow block bushings with pillow block ball bearings, rerouted and dressed the poor wiring in the control section, and than tested it. And it tested within spec. Both compressors came on, all the currents measured within specs. Pretty happy about that. I also found that the factory worker who put the top on had stripped out 3 or more screw holes that hold the cover in place, grrr. So it rattles a little bit when either compressor switches on. But it seems it settled down as I haven’t heard it since the first time I turned it on.
So here it is installed. I won’t say much about the difficulty with installing this in the rack and frame of the RV but I will say that the tolerances were measured and this new heat pump is the same dimensions as the original, but it does take some finagling to get it in the compartment. The main problem is getting it squished up against the foam seal from the return air plastic vent that drops down from the bedframe. Getting it to go that last inch to under that lip is a bitch. Once it’s mostly under the lip, then have to quickly start ratcheting the bolts to raise the tray. Took over an hour to get it positioned just right and under the lip, and the tray lifted without damaging the frame of the heat pump by prying too much with a crow bar and a flat bar.
